Chassis Model | SX3254DM324 | |
Overall Dimension (Length× Width× Height) (mm) | 7529×2490×2958 (main vehicle) | |
Gross Weight of Trailer (kg) | 40000 | |
Maximum Gross Weight of Main Vehicle (kg) | 25000 | |
Dead Weight (kg) | 10500 (with rotary table) | |
Maximum Driving Speed (km/h) | 90 | |
Distance between Axles (mm) | 3200+1350 | |
Engine | Model | WP10.290E32 |
Power (kW/rpm) | 247/2200 | |
Torque (N·m/rpm) | 1350/1100~1600 | |
Clutch | 430B series pull-type diaphragm spring clutch | |
Gearbox | Model | 9JS135 |
Velocity Ratio | 10.73 7.98 5.91 4.38 3.29 2.45 1.82 1.35 1.00 0.75 R1 10.49 R2 2.39 | |
Drive Axle | STR 16 double axle, velocity ratio of 4.42 | |
Braking Type | Service braking: dual-circuit, pneumatic braking Parking braking: (manual braking) energy-storage spring type braking |
|
Truck Cab | F2000 medium-length cab, with protective fence | |
Electrical System | 24V, negative earth | |
Tire | 12.00-20/12.00R20 18PLR all steel radial tire | |
Oil Tank Capacity (L) | 400 main oil tank plus 400 additional oil tank | |
Trailer | Cab protection frame, Mounting platform, Trailer frame, 2 trailer axles, Balance shaft assembly, Main vehicle and trailer tray, Traction bar, Rotary table assembly, Nine 12.00 tires |
