Tare Weight | About 9-13T |
Dimension | 16000mm ×3500mm (Size can be tailored to suit individual needs.) |
Loading Capacity (T) | 60T |
Axle | 13 T/16T, FUWA /BPW /Huajing Brand |
Rim | 6.5-20/7.5-20/8.00-20/8.5-20 (specially intended for oversea market) |
Tire | 8.25R20/10.00R20/11.00R20/12.00R20 |
Suspension | Mechanical suspension (German or American type) or air suspension (Chinese brand or BPW brand ) (specially intended for oversea market) |
Spring Leaf | 90(W)mm×13(Thickness)mm×10 layers or 100mm×12mm×12layers (specially intended for oversea market) |
King Pin | JOST brand 2.0 or 3.5inch (bolted or welded type) |
Landing Gear (support leg) | JOST brand D200T or Chinese brand 28Tons (Double speed) |
Main Beam | Height: 450mm-520mm Upper plate: 14mm-25mm Middle plate: 8mm-12mm Lower plate: 16mm-25mm; Material: Q345B Steel |
Side Beam | 16mm -30mm steel channel (Material: Q235steel) |
Bottom Platform | 3-6mm thick checkered plate |
Ladder | Manually operated or hydraulic type |
Gooseneck | Optional |
Brake Chamber | WABCO RE 6 relay valve; T30/30+T30 spring brake chamber (TKL brand); 45L air tanks (Specially intended for oversea markets) |
ABS | Optional |
Twist Locks | Four ,Eight or Twelve pieces (lifting type or screw type) |
Valve | WABCO valve |
Light | LED light(Specially intended for oversea markets) |
Voltage | 24V |
Socket(Receptacle) | 7-pin Socket (for 7 wire harness) |
Tool Box | 1m × 0.5m × 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs.) |
Semi Trailer Surface Coating | Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats. |
Shipping Terms | Transported by the bulk carrier in an RORO or 40HQ container. |
