Technical Parameters |
Tanker Body |
Dimension(mm) |
11250mm×2500mm×3990mm |
Tare weight |
About 10840kg |
Total Volume (m³) |
45 m³ |
Tanker Body Material |
4mm Q235 carbon steel |
End Plate |
5mm Q235 carbon steel |
Manhole Cover |
Carbon steel API manhole cover, 500mm(diameter),Three Manhole |
Bottom Valve |
Carbon steel API Pneumatic Bottom Valve |
Discharging Valve |
Diameter is 4 inch |
Number Of Compartments |
1 |
Discharging Pipe |
4”rubber hose, 2 pcs , 6m/each |
Engine |
Diesel engine;Weichai brand model: 4102 |
Air compressor |
Bohai brand 12m³ |
Chassis |
Main Beams |
Welded design or Special design I beam, connected by bolts and nutsQ345 carbon steel material |
Axle |
3 axles,FUWA brand |
Landing Gear |
CHINA BRAND 28T |
King Pin |
3.5 inch bolt-in king pin |
Suspension |
Mechanical suspension |
Leaf Spring |
90(W)mm×13(Thickness)mm×10 layers |
Pneumatic Braking System |
WABCO RE 6 relay valve; Spring brake chamber (TKL brand ); one piece of 45L air tank |
Rim |
9-22.5 |
Tire |
12.00R22.5 |
Painting |
Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats. |
Accessories |
One standard tool box |
