Gross Weight |
Approx. 5.5 tons |
Dimension(mm) |
12450 × 2490 × 1557 ( 40FT) |
Loading Capacity (Ton) |
≤ 45 T (40FT) |
AXLES |
13 T /PER , FUWA Brand, BPW Brand, or Huajing Brand |
Tire |
12.00R22.5 or 315/80R22.5Chinese Brand or according to customer requirements |
Rim |
9.00-22.5 Chinese Brand |
Suspension |
Mechanical suspension (German or American type)Or Air suspension (Chinese brand or BPW brand ) |
Spring Leaf |
90(W)mm×13(Thickness)mm×10 Layers or 100mm×12mm×12 layers |
King Pin |
JOST Brand 2.0 or 3.5inch (bolted or welded) |
Landing Gear |
JOST Brand D200T or Chinese Brand 28Tons (Double-speed) |
Main Beam |
Height: 500mm Upper plate: 14mm Middle Plate: 8mmBottom Plate is 16mm; Material: Q345B Steel |
Side Beam |
16mm or 18mm steel channel (Material: Q235steel ). |
Brake Chamber |
WABCO RE 6 relay valve; T30/30+T30 spring brake chamber (TKL brand), 45L air tank |
Twistlocks |
4, 8, or 12 sets (lifting or screw Type) |
Valve |
WABCO valve |
ABS |
Optional |
Light |
LED light |
Voltage |
24V |
Socket(Receptacle) |
7-pin Socket (for 7 wire harness) |
Tool Box |
1m × 0.5m × 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs.) |
Painting |
Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats. |
Shipping Terms |
Transported by the bulk carrier in an RORO or 40HQ container. |
