| ITEM | Parameters | |
|---|---|---|
| Weight | 16000kg | |
| Max. speed | 78km/h | |
| Dimensions | Length | 9588mm |
| Width | 2490mm | |
| Height | 3688mm | |
| Engine | Type | Water-cooled, straight 6-cylinder, 4-stroke and turbocharged diesel engine |
| Model | ISME345 20 | |
| Displacement | 10800mL | |
| Power | 254kW/1800rpm | |
| Emission standard | Euro III | |
| Pumping system | Delivery cylinder bore | 215mm |
| Distribution valve | “D” valve | |
| Theoretical concrete displacement | Low pressure 107 m3/h | |
| High pressure 74 m3/h | ||
| Theoretical pumping pressure | Low pressure 5.4 MPa | |
| High pressure 8.2 Mpa | ||
| Hopper capacity | 0.45m3 | |
| Feeding height | 1.48m | |
| Slump scope | 140–230mm | |
| Maximum aggregate size | 40mm | |
| System pressure | 31.5MPa | |
| Pressure cut-off | Automatic | |
| Transmission | Model | Fast 8JS180T-B |
| Operation mode | Manual | |
| Forward gears | 8 | |
| Pumping gear | 8 | |
| Water pump | Drive method | Hydraulic drive |
| Cleaning output | 12.7L/min | |
| Chassis model | Shanqi SX1167DR511 | |
| Chassis drive mode | 4×2 | |
| All cabs equipped with A/C, sleeper | ||
| Wheelbase | 1–2 shaft | 5100mm |
| 2–3 shaft | – | |
| 3–4 shaft | – | |
| Tread | 1 shaft | 2036 mm |
| 2 shaft | 1860 mm | |
| Tire model | 11.00R22.5 | |
| Minimum turning radius | 9.5m | |
| Braking distance | ≤9.5m/30km/h | |
| Boom | Boom folding style | “Z” |
| Quantities | 4 sections | |
| Turning angle of boom | 90° /180° /235° /220° | |
| Rotation angle of turntable | Any angle | |
| Vertical reach | 25.9m | |
| Reach depth | 12.6m | |
| Horizontal reach | 22.5m | |
| Delivery pipe size | 125mm | |
| Hose length | 3m | |
| Hydraulic system pressure | 27.4MPa | |
| Outrigger | Outrigger spread method | Manual |
| Outrigger spread L-R front | 5.4m | |
| Outrigger spread L-R rear | 5.4m | |
| Hydraulic system pressure | 25MPa | |
| Power system | Transfer case | Japan Nikko |
| Master pump | Japan Mitsubishi | |
| Boom/ outrigger pump |
Japan | |
| Control method | Manual/remote | |
| Remote controller | Japan | |
| Water tank capacity | 420L | |
| Tank capacity | 200L | |
| Hydraulic oil cooling method | Air cooled | |
