| Feature | This Trailer is made on the bassis of flatbed trailer,but it has multifunction,For Example.
1.it can transport container if we add twist lock 2.it will be sidewall semi trailer if we add side wall 3.it will be sidestake semi trailer or livestock semi trailer if we add side wall and side stake. |
| Tare Weight | About 7.1T |
| Dimension | 13000mm × 2600mm× 1575mm |
| Loading Capacity (T) | ≤ 100 T |
| Axle | 13 T/16T, FUWA /BPW /Huajing Brand |
| Rim | 9.00-22.5 or 9.75-22.5 |
| Tire | 12.00R22.5/ 315 80R22.5 |
| Suspensions | Mechanical suspension (Germany or America type)Or air suspension (China brand or BPW brand ) |
| Spring Leaf | 90(W)mm×13(Thickness)mm×10 layers or 100mm×12mm×12(specially intended for overseas markets) |
| King Pin | JOST brand 2.0 or 3.5inch (bolted or welded) |
| Landing Gear (Support Leg) | JOST brand D200T or China brand 28Tons (Double speed) |
| Main beam | Height: 500mm Upper plate: 14mm Middle plate: 8mm Bottom plate: 16mm Material: Q345B Steel |
| Side Beam | 16mm or 18mm steel channel (material: Q235steel). |
| Platform | 3mm-thick checkered plate |
| Brake Chamber | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber (TKL brand); 45L air tanks |
| ABS | Optional |
| Twist Locks | Four ,Eight or Twelve pieces (lifting type or twist Screw type)(specially intended for oversea market ) |
| Valve | WABCO valve (specially intended for oversea market ) |
| Light | LED light (specially intended for oversea market ) |
| Voltage | 24V |
| Socket(Receptacle) | 7-pin Socket (for 7 wire harness) |
| Tool Box | 1m × 0.5m × 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs.) |
| Painting | Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats. |
| Shipping Terms | Transported by the bulk carrier in an RORO or 40HQ container. |
